Optical Autorefractor

HTSY® is a professional manufacturer of ophthalmic optical equipment in China. It has launched the 980 and 8500 series Optical Autorefractor. These products use advanced optical design, high-speed image processing and smart automation tech. They measure key readings quickly and accurately—things like refractive power, corneal curvature and astigmatism. These devices are simple to use, with steady, reliable results. It is very suitable for efficient vision screening and refraction in ophthalmic clinics, optometry centers and optical shops.

Send Inquiry

Product Description

The HTSY® 980 and 8500 series optical autorefractor are advanced ophthalmic diagnostic devices built by the company on a mature technology platform. This series uses a new generation of high-resolution optical imaging system. It can capture clear and delicate retinal images, laying a solid foundation for subsequent accurate analysis. The product equipment is equipped with automatic tracking, focusing and measurement functions. It is also equipped with an electrically adjustable jaw support, which can quickly adapt to the sitting postures of different patients, making the inspection process more efficient and more comfortable. The equipment also has a built-in high-speed thermal printer. After the measurement is completed, it can automatically print and cut the inspection report. The intuitive color touchscreen interface, together with clear icon guidance, allows doctors and technicians to get started easily. It ensures each measurement is simple, fast and the data is accurate.

Product Paramenters

Two models are available

Model: ARK-980

Data Transfer	RS232 (Standard), Bluetooth, VGA, and WIFI (Optional)
Sphere	-25.00 to +25.00 D (0.01 / 0.06 / 0.12 / 0.25 D step) (VD = 12 mm)
Cylinder	1°–180° (1° step) Cylinder form: –, +, ±
Pupillary Distance (PD)	10–85 mm
Minimum Measurable Pupil Diameter	1.0 mm
Measurement Light Energy	<30 μW (ensures measurement safety)
Radius of Curvature	5.0–10.0 mm (0.01 mm step)
Corneal Power	33.00 D–67.00 D (based on corneal equivalent refractive index of 1.3375)
Corneal Astigmatism	0.00–15.00 D (0.06 D / 0.12 D / 0.25 D step)
Data Storage	Up to 10 measurements per eye (left and right)
Chart	Automatic chart
Monitor	SHARP 10.4-inch TFT LCD touch screen (adjustable viewing angle)
Built-in Printer	57 mm thermal printer with automatic paper cutting
Electrical	AC 100–240 V, 50/60 Hz
Weight	N.W.: 24 kgG.W.: 26.5 kg

Model: ARK-8500

Vertex Distance (VD) Range	0.0, 12.0, 13.75, 15.0 mm
Spherical Power Range	-20.00 D to +20.00 D (VD = 12 mm, in increments of 0.01 / 0.06 / 0.12 / 0.25 D)
Cylindrical Power Range	0.00 D to +10.00 D (in increments of 0.06 / 0.12 / 0.25 D)
Axis	1° to 180° (in 1° steps)
Cylinder Sign	–, +, ±
Pupillary Distance (PD)	10 to 86 mm
Minimum Pupil Size	2.0 mm
Average Measurement Time	<0.5 seconds
Pupil Distance	2.00 to 8.00 mm
Maximum Illuminance	<30 µW (ensures safety)
Radius of Curvature	5.0 to 10.0 mm (in 0.01 mm steps)
Refractive Power	33.00 D to 67.00 D (based on a corneal equivalent refractive index of 1.3375)
Corneal Power	0.00 D to 15.00 D (in increments of 0.06 D / 0.12 D / 0.25 D)
Data Storage	10 sets of data for left/right eyes
Axis	1° to 180°
Target	Automatic fogging
Monitor	9-inch flip-type TFT touch screen
Printer	57 mm width, with automatic paper cutting
Power Supply	AC 100–250 V, 50/60 Hz, wide voltage range
Net Weight	22 kg
Gross Weight	26.5 kg
Package Dimensions	(L) 680 mm × (W) 400 mm × (H) 640 mm

$Optical Autorefractor$

ARK-980

$Optical Autorefractor$

ARK-8500

Treatment Mechanism

1.Advanced Optical and Imaging System

The HTSY® automatic refractometer works on the principle of high-precision Hartmann-type refractometer. It is combined with an innovative optical path design and high-definition imaging components. This ensures the capture of high-quality fundus images. With adaptive high-speed image acquisition and intelligent recognition algorithms, the system can effectively analyze various optical characteristics of the eyeball. It provides solid and reliable data for refractive calculation.

$Optical Autorefractor$

2.Intelligent Automatic Measurement

The equipment is equipped with a high-performance 32-bit embedded processor and is also equipped with a precise motion control module, which can quickly and stably track and locate the pupils. It has an automatic eye position memory function. During repeated measurements, it can quickly return to the previously recorded position, greatly improving the efficiency of continuous measurements. The whole measurement process is highly automated. It minimizes errors caused by manual operation to the greatest extent.

$Optical Autorefractor$

3.Integrated and Convenient Design

The HTSY® refractometer adopts an integrated design of measurement, display and printing. It is equipped with a large-size LCD touchscreen with adjustable viewing angle. It is convenient for observation and operation from different angles. This machine comes with a built-in thermal printer. Once a measurement is done, the report prints and cuts out automatically. This spares the hassle of manual work and streamlines the whole workflow. It features a sturdy, modular design that keeps it running reliably and durably, and daily maintenance is simple and straightforward.
